Ubiquiti UDM-Pro-Max, Dream Machine Pro Max

Email
Product SKU : UDM-Pro-Max
Array
Description

Ubiquiti UDM-Pro-Max, Dream Machine Pro Max

Technical parameters

Connectors and Interfaces

WAN Ports:1
WAN speed:(1) 10/100/1000/2500Mbps + (1) 10Gbps SFP+
Number of HDD slots:1
Multiple WAN:Yes
LAN speed:(8) 10/100/1000Mbps + (1) 10Gbps SFP+
Gigabit LAN:Yes
Optical interfaces:(2) 1G/10Gbps
Other features:Bluetooth

Power

Power type:Mains power (230V), UniFi SmartPower RPS
Redundant power supply:Yes
Max. power consumption [W]:60
Power via connector/terminal:230V AC

Physical characteristics

Design:Rackmount
Fans:(1) 60 x 60 mm
Chassis design:Metal
Buttons:Reset
Operating temperature [°C]:-10 up to 40
Weight [g]:5
Width [mm]:442
Height [mm]:44
Depth [mm]:286

Hardware

CPU:ARM Cortex-A57
CPU frequency [MHz]:2000
CPU cores:4
RAM [MB]:8192

Software

Supported VPN:PPTP, L2TP, IPSec, OpenVPN
Pre-installed controller:UniFi Network, UniFi Protect, UniFi Talk, UniFi Access
Management:Web management, UniFi Network
IPv6 support:Yes
